Description
Maintain optimal braking performance and complete highway safety under maximum load weights with the rugged Automann 160.K71378 Electric Trailer Brake Magnet Kit. Built to handle the severe duty cycles of commercial freight, flatbed, and heavy utility trailers, this complete replacement kit provides the precise electrical conductivity and mechanical engagement needed to actuate heavy-duty drum brakes instantly when your in-cab brake controller applies voltage.
Manufactured using premium components, this Automann kit features upgraded, heat-resistant insulated lead wires designed to withstand severe road vibrations, moisture, and debris. Each box delivers an all-in-one overhaul solution for your brake backing plate, packing the high-performance replacement magnet assembly along with its corresponding high-tensile spring and precision retention clip. Upgrading to this premium kit eliminates common commercial trailering headaches like uneven brake pulling, weak deceleration, or complete terminal arcing.
Key Features & Specifications:
Premium Automann Quality: Manufactured to precise engineering tolerances for a reliable, cost-effective alternative to factory components.
Part Number: 160.K71378
Broad Axle Compatibility: Engineered specifically to service heavy-duty 7,200 lb., 8,000 lb., 9,000 lb., 10,000 lb., 12,000 lb., and 15,000 lb. electric brake axles.
Exact Brake Dimension Matching: Designed for standard heavy commercial 12-1/4" diameter electric drum brake networks built after June 1992.
All-In-One Service Hardware: Includes the primary heavy-duty magnet assembly, a high-retention clip, and a heavy-duty centering spring.
Universal Layout Optimization: Designed as a non-handed component that fits seamlessly onto either the left-hand (driver side) or right-hand (passenger side) brake backing plate assemblies.
Direct OEM Interchangeability: Replaces Dexter Axle K71-378-00, Sirco K71-378, and Traction 7010531 variants.
Application & Installation Notes:
This heavy-duty electric brake magnet kit is optimized for trailer backing plates manufactured after June 1992. For ideal on-road safety and balanced stopping force, always replace your trailer magnets in pairs across the same axle. During the electrical connection setup, it is highly recommended to use watertight heat-shrink butt connectors to safeguard the lead wires from moisture intrusion, road grime, and harsh winter road salt contamination.
